Static Model Compare Configuration

Engine

• Engine Type: 2.3-Litre Turbo Gasoline, 3.0-Litre V6 Turbo Diesel
• Engine Size (cm³): 2261, 2993
• Compression Ratio: 10:1, 16.0:1
• Maximum Power: 184 @ 3250, 222 @ 5900
• Maximum Torque: 452 @ 3350, 600 @ 1750-2250
• No. of Valves: 16, 24
• Bore x Stroke (mm): 84.01x90.03, 87.50x94
• Fuel Management System: Direct Cylinder Injection
• Starter - Stop / Start System

Transmissions

• 10-speed automatic transmission

Driveline

• RWD
• Full Time 4WD with Electromagnetic Transfer Case (eMTC)
• Selectable Drive Modes with Push Button: Normal, Eco, Tow, Slippery
• Selectable Drive Modes with Rotary Dial: Normal, Eco, Tow, Slippery, Mud, Sand

Fuel

• Combined Fuel Economy (L/100km)(Auto): 8.3, 9.3
• CO₂ Emissions (g/km)(Auto): 213, 218
• Fuel Tank Capacity (L): 80
• Fuel Type: Petrol, Diesel

Exterior Dimensions (mm)

• Vehicle Length - with rear bumper (where fitted): 5350
• Vehicle width (with mirrors extended): 2208
• Vehicle width (with mirrors folded): 2015
• Vehicle width (without mirrors): 1918
• Overall Height: 1877, 1886
• Approach Angle: 30
• Departure Angle (Without Tow Bar): 25.6
• Departure Angle (With Tow Bar): 23
• Overhang - Front: 865
• Overhang - Rear: 1215
• Track - Front / Rear: 1620
• Wheelbase: 3270
• Ground clearance (unladen, mm): 237
• Wading Depth (mm): 800
• Ramp Breakover Angle (degrees) : 22
• Turning Circle - Kerb to Kerb (m) : 12.9

Interior Dimensions (mm)

• Front Headroom: 1024
• Front Legroom: 1057
• Front Shoulder Room: 1450
• 2^nd Row Headroom: 989
• 2^nd Row Legroom: 879
• 2^nd Row Shoulder Room: 1440

Vehicle Masses (kg)

• Kerb Weight - Total: 1968, 2055, 2167, 2255
• Payload: 1045, 1092, 1093, 1095
• Gross Vehicle Mass: 3060, 3100, 3260, 3350
• Gross Combined Mass: 6250, 6450, 6500
• Maximum Braked Towing Capacity: 3500

Chassis & Suspension

• Front & Rear Suspension: Standard Duty Suspension, Standard Duty with montube dampers
• Brake Front / Rear: Power 4-Wheel Disc
• Steering System: Power Steering
• Locking Differential: Rear
• Park Brake: Electronic
• eShifter
• Tow Bar

Wheels

• Wheel Size & Type: 18″ Alloy
• Tyre: 255/65 R18 A/S, 255/65 R18 A/T
• Spare Wheel: 18″ Alloy

Exterior

• Exterior Lighting - Headlamps: LED
• Exterior Lighting - Taillamps: LED
• Exterior Lighting - Front Fog Lamps: LED
• Centre High Mounted Stop Light
• Exterior Lighting - Daytime Running Lamps: LED
• Exterior Lighting - Auto Headlamp on-off
• Exterior Lighting - Zone Lighting
• Exterior Door Handles - Colour: Accent
• Exterior Mirrors - Colour: Accent
• Exterior Mirrors - Functionality: Power Adjust, Power Fold, Heat, Turn Signal, Puddle lamp
• Front Bumper: Body Colour
• Grille: Black
• Recovery Hook: Front (x2)
• Plastic Under Body Spash Protection
• Steel Underbody Protection(Front, Engine and Transfer Case and Fuel Tank Guard)(O)
• Side Step
• Mud Flaps: Front & Rear
• Rear Bumper: Black
• Load Box Access Step

Load Box Elements

• Spray-In Bedliner
• Power To The Box - 12V & 400W Inverter
• Box Top Protective Capping with Load Box Access Caps
• Internal Tie Down Points
• Tailgate Clamp Pockets
• Tailgate Ruler & Cupholders
• Tailgate Lock: Power
• Tailgate with Lift Assistance

Interior, Seating and Door Trim

• Vinyl Wrapped Steering Wheel & Leather Gear Knob
• Steering Wheel Manual Adjustment (Reach & Rake)
• Seat Material: Partial Leather
• Adjustable Driver's Seat: 8-Way Power Seat Adjust (Track/ Recline/ Height adjust/ Lumbar)
• Adjustable Passenger's Seat: 6-Way Manual Adjust (Track/ Recline/ Height adjust)
• Child Seat ISOFIX Anchorage Points (x 2)
• Floor Covering: Carpet

Comfort and Convenience

• Centre Console with Single Lid and 2 Cup Holders
• Pop Out Cup Holders
• Charging
  • Auxillary 12V Power Outlet - Centre Console Bin
  • Auxillary 12V Power Outlet - Rear of Centre Console
  • USB Ports (USB A and USB C) - centre console
  • Wireless Charger
  • Power To The Box - 12V
• Climate Control: Dual Zone Automatic
• 2^nd Row Rear Console A/C Vents
• Power Windows: Front Only, Front & Rear
  • 1 Touch Up & Down with Global Open & Close: Driver / Passenger
• Rain Sensing Windscreen Wipers
• Rear Window Defrost
• Rear View Mirror: Electrochromatic
• Underseat Stowage

Audio And Communication

• Vehicle's Modem connected to Ford app
• Ford app featuring remote start (AT only), lock / unlock, vehicle locator, vehicle health alerts, vehicle status oil life, enhanced customer connectivity settings
• Digital Instrument Cluster with Configurable Display: 8″
• Colour Multi-Function Touch Screen Display: 12″ screen
• Speakers: 6
• AM/FM Stereo Radio
• Bluetooth^® with Phone / Audio Streaming
• Satellite Navigation
• SYNC^® 4A
• Steering Wheel Audio/Function Control
• Wireless Apple CarPlay^TM & Android Auto^TM

Safety and Security

• Alarm with Perimeter, Interior Motion & Vehicle Inclination Sensors
• Airbags - Dual Front, Front Side, Curtain
• Airbags - Dual Front, Front Side, Curtain & Driver Knee
• 3 Point Lap Sash Seat Belt - All Positions
• Post-Collision Braking
• Power Door Dead Locks
• Smart Keyless Entry with Push Button Start
• Immobilizer

Driver Assistance

• Adaptive Cruise Control with, Stop & Go & Lane Centering
• Adjustable Speed Limiter
• Blind Spot Monitoring
• Rear Cross Traffic Alert
• Dynamic Stability Control (DSC) incorporating ABS, Load Adaptive Control, Roll Over Mitigation, Traction Control & Trailer Sway Control
• Hill Launch Assist
• Hill Descent Control
• Lane Keeping System with Road Edge Detection
• Pre-Collission Assist
  • Dynamic Brake Support
  • Forward Collision Warning System
  • Autonomous Emergency Braking (AEB) with Pedestrian Detection
• Reverse Brake Assist
• Parking Sensors: Front & Rear
• 360 Degree Camera
• Tyre Pressure Monitoring System

Towing

• Maximum Braked Towing Capacity: 3500
• Trailer Light Check
• Tow Haul Mode (part of Selectable Drive Modes)
• Blind Spot Monitoring with Trailer Coverage
• Recovery Hooks: Front (x2)

Off Road

• Off Road Screen
• Auxillary Upfitter Switches(O)

Color Options

• Command Grey(O)
• Frozen White(O)
• Blue Lightning(O)
• Agate Black(O)
• Iconic Silver(O)
• Lucid Red(O)
• Carbonized Gray(O)

Stand-Alone Options

• Flexible Rack System(O)
• Cargo Management System(O)
• Underbody Protection(O)
• Fuel Tank Guard(O)
• Pro Trailer Backup Assist(O)
• Sports Bar - Black(O)
• Pro Trailer Backup Assist(O)
