Static Model Compare Configuration

Engine

• Engine Type: 2.0-Litre Single Turbo Diesel
• Engine Size (cm³): 1996
• Compression Ratio: 15.8:1
• Maximum Power: 125 @ 3500
• Maximum Torque: 405 @ 1750-2500
• No. of Valves: 16
• Bore x Stroke (mm): 84.01x90.00
• Fuel Management System: Direct Cylinder Injection

Transmissions

• 6-speed manual transmission, 6-speed automatic transmission, 10-speed automatic transmission

Available Bodystyles

• Single Cab, Super Cab, Double CabCO₂ Emissions (g/km)(Manual)^1.

Driveline

• RWD
• 4x4 with Electronic Shift On The Fly (ESOF)

Fuel

• Combined Fuel Economy (L/100km)(Manual): 6.9, 7.1
• CO₂ Emissions (g/km)(Manual)¹: 181, 187
• Combined Fuel Economy (L/100km)(Auto): 7.5, 7.7
• CO₂ Emissions (g/km)(Auto): 197, 203
• Fuel Tank Capacity (L): 80
• Fuel Type: Diesel

Exterior Dimensions (mm)

• Vehicle Length - with rear bumper (where fitted): 5320, 5350
• Vehicle width (with mirrors extended): 2208
• Vehicle width (with mirrors folded): 2015
• Vehicle width (without mirrors): 1918
• Overall Height: 1883, 1877, 1886
• Approach Angle: 30
• Departure Angle (Without Tow Bar): 25.6
• Departure Angle (With Tow Bar): 23
• Overhang - Front: 865
• Overhang - Rear: 1193, 1215
• Track - Front / Rear: 1620
• Wheelbase: 3270
• Ground clearance (unladen, mm): 234, 237
• Wading Depth (mm): 800
• Ramp Breakover Angle (degrees) : 22
• Turning Circle - Kerb to Kerb (m) : 12.9

Interior Dimensions (mm)

• Front Headroom: 1024
• Front Legroom: 1057
• Front Shoulder Room: 1450
• 2^nd Row Headroom: 989
• 2^nd Row Legroom: 879
• 2^nd Row Shoulder Room: 1440

Vehicle Masses (kg)

• Kerb Weight - Total: 1939, 2004, 2027, 2096, 2184, 2124, 2153, 2220, 2243
• Payload: 907, 936, , 947, 964, 970, 1006, 1121, 1186, 1163
• Gross Vehicle Mass: 3060, 3190
• Gross Combined Mass: 6150, 6300
• Maximum Braked Towing Capacity: 3500

Chassis & Suspension

• Front & Rear Suspension: Standard Duty Suspension
• Brake Front / Rear: Front Disc / Rear Drum brakes
• Steering System: Power Steering
• Locking Differential: Rear
• Park Brake: Mechanical
• Tow Bar(S)
• Tow Hitch(O)

Wheels

• Wheel Size & Type: 17″ Alloy
• Tyre: 255/70 R16 A/S
• Spare Wheel: 16″ Steel

Exterior

• Exterior Lighting - Headlamps: Halogen
• Exterior Lighting - Taillamps: Halogen
• Centre High Mounted Stop Light(S)
• Exterior Lighting - Daytime Running Lamps: Halogen
• Exterior Lighting - Auto Headlamp on-off(S)
• Exterior Door Handles - Colour: Black
• Exterior Mirrors - Colour: Black
• Exterior Mirrors - Functionality: Power Adjustable, Manual Fold
• Front Bumper: Body Colour
• Grille: Black
• Recovery Hook: Front (x1)
• Plastic Under Body Spash Protection(S)
• Steel Underbody Protection( Front , Engine and Transfer Case and Fuel Tank Guard)(P)
• Side Step(O)
• Mud Flaps: Rear
• Mud Flaps: Front & Rear
• Rear Bumper: Black
• Load Box Access Step

Load Box Elements

• Spray-In Bedliner(O)
• Box Top Protective Capping with Load Box Access Caps(S)
• External Tie Down Rail(S)
• Internal Tie Down Points(S)
• Tailgate Clamp Pockets(S)
• Tailgate Ruler & Cupholders(S)
• Tailgate Lock: Manual
• Tailgate with Lift Assistance(S)

Interior, Seating and Door Trim

• Steering Wheel Manual Adjustment (Reach & Rake)(S)
• Seat Material: Cloth
• Seat Functionality: Manual
• Adjustable Driver's Seat: 4-Way Manual Adjust (Track/ Recline)
• Adjustable Passenger's Seat: 4-Way Manual Adjust (Track/ Recline)
• Child Seat ISOFIX Anchorage Points (x 2)
• Floor Covering: Carpet
• Floor Mats: Front Rubber Mats

Comfort and Convenience

• Centre Console with Single Lid and 2 Cup Holders(S)
• Pop Out Cup Holders(S)
• Charging
  • Auxillary 12V Power Outlet - Centre Console Bin(S)
  • Auxillary 12V Power Outlet - Rear of Centre Console
  • USB Ports (USB A and USB C) - centre console(S)
• Climate Control: Single Zone Manual
• 2^nd Row Rear Console A/C Vents(P)
• Power Windows: Front Only
  • 1 Touch Up & Down with Global Open & Close: Driver / Passenger
• Power Windows: Front & Rear
  • 1 Touch Up & Down with Global Open & Close: Driver / Passenger
• Rear View Mirror: Manual Day/Night Inside
• Underseat Stowage

Audio And Communication

• Vehicle's Modem connected to Ford Cloud
• Ford app featuring remote start (AT only), lock / unlock, vehicle locator, vehicle health alerts, vehicle status oil life, enhanced customer connectivity settings
• Digital Instrument Cluster with Configurable Display: 8″
• Colour Multi-Function Touch Screen Display: 10.1″ screen
• Speakers: 2, 4
• AM/FM Stereo Radio(S)
• Bluetooth^® with Phone / Audio Streaming(S)
• SYNC^® 4A(S)
• Steering Wheel Audio/Function Control(S)
• Wireless Apple CarPlay^TM & Android Auto^TM (S)

Safety and Security

• Alarm with Perimeter, Interior Motion & Vehicle Inclination Sensors(S)
• Airbags - Dual Front, Front Side, Curtain
• Airbags - Dual Front, Front Side, Curtain & Driver Knee
• 3 Point Lap Sash Seat Belt - All Positions
• Power Door Dead Locks(S)
• Immobilizer(S)

Driver Assistance

• Cruise Control(S)
• Adjustable Speed Limiter(S)
• Dynamic Stability Control (DSC) incorporating ABS, Load Adaptive Control, Roll Over Mitigation, Traction Control & Trailer Sway Control(S)
• Hill Launch Assist(S)
• Hill Descent Control(S)
• Parking Sensors: Rear
• Rear View Camera(S)

Towing

• Maximum Braked Towing Capacity: 3500
• Trailer Light Check(S)
• Recovery Hooks: Front (x1)

Option Packages

XL Upgrade Pack 4

• 4 Speakers (SGL Cab) / 6 Speakers (Rap Cab & DC)(O)
• DEATC (Rap Cab & DC only - rear vents DC only)(O)
• Underbody Protection(O)
• Plastic Fuel Tank Guard(O)
• 17″ Alloy Wheels - All Terrain (Steel Spare)(O)
• Wheel Lug Lock(O)

XL Upgrade Pack 5

• Grille - Chrome(O)
• Front Fender - Bright(O)
• Side Mirror - Chrome(O)
• Door Handles - Chrome(O)
• Rear Bumper - Plastic(O)
• 4 Speakers (SGL Cab) / 6 Speakers (Rap Cab & DC)(O)
• DEATC (Rap Cab & DC)(O)
• 17″ Alloy Wheels - All season (Steel Spare)(O)
• Wheel Lug Lock(O)

XL Upgrade Pack - XL Plus (DC Only)

• Sports bar(O)
• Spray in bed-liner(O)
• 18″ Alloy Wheels(O)
• Bodyside Decal(O)
• Ranger Tailgate Decal(O)

Stand-Alone Options

• Plastic Side Step(O)
• Spare Tire Lock(O)
