Static Model Compare Configuration

Engine

• Engine Type: 2.0-Litre Single Turbo Diesel
• Engine Size (cm³): 1996
• Compression Ratio: 15.8:1, 16.0:1
• Maximum Power: 125 @ 3500, 154 @ 3750
• Maximum Torque: 405 @ 1750-2500, 500 @ 1750-2000
• No. of Valves: 16
• Bore x Stroke (mm): 84.01x90.00
• Fuel Management System: Direct Cylinder Injection

Transmissions

• 6-speed automatic transmission, 10-speed automatic transmission

Available Bodystyles

• Super Cab, Double Cab

Driveline

• RWD
• 4x4 with Electronic Shift On The Fly (ESOF)
• Selectable Drive Modes with Push Button: Normal, Eco, Tow, Slippery

Fuel

• Combined Fuel Economy (L/100km)(Auto): 7.2, 7.5, 7.7
• CO₂ Emissions (g/km)(Auto): 188, 195, 197, 203
• Fuel Tank Capacity (L): 80
• Fuel Type: Diesel

Exterior Dimensions (mm)

• Vehicle Length - with rear bumper (where fitted): 5350
• Vehicle width (with mirrors extended): 2208
• Vehicle width (with mirrors folded): 2015
• Vehicle width (without mirrors): 1918
• Overall Height: 1877, 1886
• Approach Angle: 30
• Departure Angle (Without Tow Bar): 25.6
• Departure Angle (With Tow Bar): 23
• Overhang - Front: 865
• Overhang - Rear: 1215
• Track - Front / Rear: 1620
• Wheelbase: 3270
• Ground clearance (unladen, mm): 237
• Wading Depth (mm): 800
• Ramp Breakover Angle (degrees) : 22
• Turning Circle - Kerb to Kerb (m) : 12.9

Interior Dimensions (mm)

• Front Headroom: 1024
• Front Legroom: 1057
• Front Shoulder Room: 1450
• 2^nd Row Headroom: 989
• 2^nd Row Legroom: 879
• 2^nd Row Shoulder Room: 1440

Vehicle Masses (kg)

• Kerb Weight - Total: 2151, 2175, 2225, 2256, 2284, 2300
• Payload: 915, 930, 946, 965, 974, 989
• Gross Vehicle Mass: 3140, 3230
• Gross Combined Mass: 6250, 6300, 6450, 6500
• Maximum Braked Towing Capacity: 3500

Chassis & Suspension

• Front & Rear Suspension: Standard Duty Suspension
• Brake Front / Rear: Front Disc / Rear Drum brakes
• Steering System: Power Steering
• Locking Differential: Rear
• Park Brake: Mechanical
• Tow Bar(S)
• Tow Hitch(S)

Wheels

• Wheel Size & Type: 17″ Alloy
• Tyre: 255/70 R16 A/S
• Spare Wheel: 16″ Steel

Exterior

• Exterior Lighting - Headlamps: LED
• Exterior Lighting - Taillamps: Halogen
• Exterior Lighting - Front Fog Lamps: Halogen
• Centre High Mounted Stop Light(S)
• Exterior Lighting - Daytime Running Lamps: LED
• Exterior Lighting - Auto Headlamp on-off(S)
• Exterior Door Handles - Colour: Body Colour
• Exterior Mirrors - Colour: Body Colour
• Exterior Mirrors - Functionality: Power Adjust, Power Fold, Turn Signal
• Front Bumper: Body Colour
• Grille: Chrome
• Recovery Hook: Front (x1)
• Plastic Under Body Spash Protection(S)
• Steel Underbody Protection( Front , Engine and Transfer Case and Fuel Tank Guard)(P)
• Side Step(S)
• Mud Flaps: Front & Rear
• Rear Bumper: Body Colour
• Load Box Access Step(S)
• Rear Sports Bar(P)

Load Box Elements

• Spray-In Bedliner(S)
• Box Top Protective Capping with Load Box Access Caps(S)
• Internal Tie Down Points(S)
• Tailgate Clamp Pockets(S)
• Tailgate Ruler & Cupholders(S)
• Tailgate Lock: Power
• Tailgate with Lift Assistance(S)

Interior, Seating and Door Trim

• Vinyl Wrapped Steering Wheel & Leather Gear Knob(S)
• Steering Wheel Manual Adjustment (Reach & Rake)(S)
• Seat Material: Cloth
• Seat Functionality: Manual
• Adjustable Driver's Seat: 6-Way Manual Adjust (Track/ Recline/ Height adjust)
• Adjustable Passenger's Seat: 4-Way Manual Adjust (Track/ Recline)
• Child Seat ISOFIX Anchorage Points (x 2)
• Floor Covering: Carpet
• Floor Mats: Front Rubber Mats

Comfort and Convenience

• Centre Console with Single Lid and 2 Cup Holders(S)
• Pop Out Cup Holders(S)
• Charging
  • Auxillary 12V Power Outlet - Centre Console Bin(S)
  • Auxillary 12V Power Outlet - Rear of Centre Console(S)
  • USB Ports (USB A and USB C) - centre console(S)
  • Wireless Charger(P)
  • Power To The Box - 12V(S)
• Climate Control: Single Zone Manual
• 2^nd Row Rear Console A/C Vents(P)
• Power Windows: Front & Rear
  • 1 Touch Up & Down with Global Open & Close: Driver / Passenger
• Rain Sensing Windscreen Wipers(S)
• Rear Window Defrost(S)
• Rear View Mirror: Electrochromatic
• Underseat Stowage

Audio And Communication

• Vehicle's Modem connected to Ford Cloud
• Ford app featuring remote start (AT only), lock / unlock, vehicle locator, vehicle health alerts, vehicle status oil life, enhanced customer connectivity settings
• Digital Instrument Cluster with Configurable Display: 8″
• Colour Multi-Function Touch Screen Display: 10.1″ screen
• Speakers: 6
• AM/FM Stereo Radio(S)
• Bluetooth^® with Phone / Audio Streaming(S)
• SYNC^® 4A(S)
• Steering Wheel Audio/Function Control(S)
• Wireless Apple CarPlay^TM & Android Auto^TM (S)

Safety and Security

• Alarm with Perimeter, Interior Motion & Vehicle Inclination Sensors(S)
• Airbags - Dual Front, Front Side, Curtain
• Airbags - Dual Front, Front Side, Curtain & Driver Knee
• 3 Point Lap Sash Seat Belt - All Positions(S)
• Post-Collision Braking(P)
• Power Door Dead Locks(S)
• Smart Keyless Entry with Push Button Start(S)
• Immobilizer(S)

Driver Assistance

• Cruise Control(S)
• Adjustable Speed Limiter(S)
• Blind Spot Monitoring with Trailer Coverage(P)
• Cross Traffic Alert(P)
• Dynamic Stability Control (DSC) incorporating ABS, Load Adaptive Control, Roll Over Mitigation, Traction Control & Trailer Sway Control(S)
• Hill Launch Assist(S)
• Hill Descent Control
• Lane Keeping System with Road Edge Detection(P)
• Pre-Collission Assist(P)
  • Dynamic Brake Support(P)
  • Forward Collision Warning System(P)
  • Autonomous Emergency Braking (AEB) with Pedestrian Detection(P)
• Parking Sensors: Front & Rear
• Rear View Camera(S)

Towing

• Maximum Braked Towing Capacity: 3500
• Trailer Light Check(S)
• Tow Haul Mode (part of Selectable Drive Modes)(S)
• Blind Spot Monitoring with Trailer Coverage(P)
• Recovery Hooks: Front (x1)

Option Packages

XLT Upgrade Pack 3

• DEATC (Rap Cab & DC only - rear vents DC only)(O)
• Wireless Charging(O)
• Partial Leather(O)
• Manual 6-Way Passenger seat adjuster(O)
• Collision Mitigation System (Pre-Collision Assist, Dynamic Brake Support , Forward Collision Warning , Automated Emergency Braking)(O)
• BLIS with Trailer coverage(O)
• Post Impact Braking(O)
• Lane Keep Assist (Lane Keeping & Road Departure warning)(O)
• Underbody Protection(O)
• Plastic Fuel Tank Guard(O)
• Spare Accessory Switches(O)
• 17″ Alloy Wheels - All Terrain (Steel Spare)(O)
• Wheel Lug Lock(O)

XLT Upgrade Pack 6

• Front Fender Grill - Black(O)
• Painted Grille(O)
• Black Sport Bar(O)
• Side Mirror - Black(O)
• Door Handles - Black(O)
• Front Bumper - Body Colour / Lower Accent(O)
• Rear Bumper - Painted Accent Colour(O)
• Fog Lamp Bezel(O)
• DEATC (Rap Cab & DC only - rear vents DC only)(O)
• Wireless Charging(O)
• Partial Leather(O)
• Manual 6-Way Passenger seat adjuster(O)
• Collision Mitigation System (Pre-Collision Assist, Dynamic Brake Support , Forward Collision Warning , Automated Emergency Braking)(O)
• BLIS with Trailer coverage(O)
• Post Impact Braking(O)
• Lane Keep Assist ( Lane Keeping & Road Departure warning)(O)
• Underbody Protection(O)
• Plastic Fuel Tank Guard(O)
• Spare Accessory Switches(O)
• 17″ Alloy Sport Wheels All terrain (Steel Spare) (O)

Stand-Alone Options

• Cargo Management System(O)
• Plastic Side Step(S)
• Spare Tire Lock(O)

Off Road

• Auxillary Upfitter Switches(P)
