Static Model Compare Configuration

ENGINE

• Type: Duratorq TDCi 2.0
• No. of cylinders: 4 in line
• Displacement (cm³): 1996
• Power (kW @ rpm): 121
• Torque (Nm @ rpm): 390
• Fuel requirement: Diesel

TRANSMISSION

• Final drive: 3.65
• Driver Modes: Normal, Eco, Tow/haul, Slippery
• Type: 8-Automatic Speed

PERFORMANCE

• Fuel Economy - NEDC ℓ/100km (combined cycle)*: 7.6
• AdBlue Injector
• CO₂ Emission : Combined [g/km]*: 201

SUSPENSION

• Front: Independent MacPherson struts, variable-rate coil springs, stabiliser bar and gas pressurised shock absorbers
• Rear suspension: leaf springs, gas-pressurised shock absorbers

STEERING

• Type: rack-and-pinion steering with rack-mounted power assisted
• Turning circle (kerb-to-kerb) (m): 11.9

BRAKES

• Front ventilated discs
• Rear solid discs
• Emergency brake warning
• Anti-lock Braking System (ABS) with Electronic Brakeforce Distribution (EBD)
• Emergency Brake Assist (EBA)

WHEELS AND TYRES

• 235/65 R16 - Steel wheel

DIMENSIONS (mm) - EXTERIOR

• Overall length (mm): 5,981
• Overall width - with mirrors (mm): 2,059
• Wheel base (mm): 3,750
• Sliding door width (mm): 1,300
• Sliding door aperture height (mm): 1,700
• Rear door width (mm): 1,565
• Rear door aperture height (mm): 1,748
• Front track (mm): 1,732
• Rear track (SRW) (mm): 1,743

DIMENSIONS - INTERIOR

• Max load length @ floor (no Bulkhead) (mm): 3,200
• Max load length @ floor (with Bulkhead) (mm): 3,044
• Max load length @ 1.2m high (with Bulkhead) (mm): 2,900
• Max load width (mm): 1,784
• Load space between wheel arches (mm): 1,392
• Load floor to roof (mm): 1,886
• Loadspace (max load) (m³): 10
• Loadspace (SAE method) (m³): 9.1
• Loadspace (VDA method) (m³): 10.8

VEHICLE MASSES

• Gross Vehicle Mass (GVM) (kg): 3,500
• Gross Combined Mass (GCM) (kg): 6,000
• Fuel tank capacity (L): 80
• Kerb weight (kg): 1,900
• Gross payload (kg): 1,325
• Towing mass (braked) (kg): 2,800
• Towing mass (unbraked) (kg): 750

SAFETY & SECURITY

• Driver airbag
• Electronic Stability Programme (ESP)
• Hill Launch Assist (HLA)
• Traction control
• Rollover Mitigation (ROM)
• Centre high-mounted rear stop lamp
• Power door locks
• Door entry remote
• Rear doors mounted with lock/unlock switch
• Drive-away locking with crash unlocking
• Door auto-relocking enabled
• Two-stage unlocking with configurable unlocking config
• Tyre Pressure Monitoring System
• Alarm & Mobiliser

COMFORT AND CONVENIENCE

• Radio with single AM/FM antenna, 2 front speakers, 2 tweeters
• USB port, Bluetooth^® and Voice Control
• Steering-wheel-mounted audio controls
• Vechile's Modem connected to Ford app
• Ford app Connect - featuring Remote Start (AT only), Lock / Unlock, Vehicle Locator, Vehicle Health Alerts, Vehicle Status, Oil Life, Enhanced Customer Connectivity Settings
• Digital Instrument Cluster with Configurable Display
• Colour Multi-Function Touch Screen Display: 12 "Screen
• SYNC^®4
• Auxiliary input
• Marketing CV Pack 1

EXTERIOR

• 180° opening Cargo doors
• Headlamps - projector-style halogen reflector lights (quad-beam)
• Manual headlamp levelling

INTERIOR, SEATING AND LOAD SPACE

• Cup Holders - 2
• Standard cloth seats
• Front driver 3-point seatbelt with pre-tensioners
• Front passenger 3-point seatbelts with load limiter
• Front power windows with driver one-touch up/down functionality
• Manual 2-Way Driver Seat
• Driver Arm Rest
• Partial floor cover - rubber insulated easy-clean (or similar)
• Load space lighting
• Load compartment floor tie-down hooks: 10

Options

• Trailer tow attachments (O)
• Heavy duty battery (O)
• Manual Aircon (O)
• Driver Assistance Package With 360 View Camera (O)

Ford PROTECT

• Comprehensive warranty: 4years / 120 000 km
• Roadside assistance: 4years / unlimited km
• Corrosion warranty: 5 years / unlimited km
• Service plan: 6
• Service intervals: 15 000 km

Paint Colours

• Frozen White
• Moondust Silver (O)

Driver Assistance Package with 360-degree Camera

• High-Mounted LED Downlight (O)
• Dual Exterior Power Mirror Power Fold Back (O)
• Collision Mitigation System 3 Level 2 (O)
• Adaptive Speed Control (O)
• Blind Spot Information System (O)
• Lane Changing Warning & Aid (O)
• Reverse Parking Aid (O)
• Front Parking Aid (O)
• Parking Slot Aid (O)
• Reverse Brake Assist (O)
• ICE Pack 3 (O)
• Front/Side/Rear View Camera (O)
• Front Fog Lamps (O)

MARKETING CV PACK #1

• Complete Rear Trim Board
• Single Side Load Door Single Side Load Door
• Kerbside Load Door
• Load Floor Liner-Moulded
• Extended Range Single FU/TNK

Delivery Assist Package

• Close Assist Side Door (O)
• Kerbside Load Doors (O)
• Keyless Entry/Start (O)
